V-GUARD 1 HP SUBMERSIBLE 110/58 85MM WINDING DATA CRNO STAMPING S.NO. TERMS VALUES 1. STAMPING TYPE  CRNO STAMPING 2. O/D – I/D 110/58MM 3. LENGTH  85MM 4. SLOT  24 5. SWG-R  23*24 6. PITCH-R  1-6,1-8,1-10,1-12 7. TURNS-R  32,33,34,35 8. SWG-S  24 9. PITCH-S 1-10,1-12 10. TURNS-S 65,65 11. WEIGHT-R 550GM 12. WEIGHT-S 270GM 13. RPM 2880 14. CAPACITOR 30 MFD 15. WINDING  WIRE COPPER 16. CONNECTION TYPE SERIES   PRESENTATION  Motor winding is an essential part of electrical designing, assuming a urgent part in...
