2 Blade 2800 RPM Farata Fan Winding Data (Copper Wire) 20mm to 1 Inch
🔧 Stamping Size – 20mm to 1 Inch | Inner Dia – 60mm
यह data खासकर high speed Farata fan (2800 RPM) के लिए है, जिसमें copper winding use की जाती है। यह motor ज्यादा speed और strong air throw के लिए use होती है।
🔧 Basic Details
Stamping Size – 20mm to 1 Inch
Inner Dye – 60 mm
Capacitor – 3.15 MFD
Winding Wire – Copper
RPM – 2800 (High Speed)
Inner Dye – 60 mm
Capacitor – 3.15 MFD
Winding Wire – Copper
RPM – 2800 (High Speed)
⚙️ Running Winding
Total Coil – 2
SWG – 33
Turn – 250
Coil Size – 30 inch
SWG – 33
Turn – 250
Coil Size – 30 inch
Coil Pitch – 1-8 = 1 Round
1-10 = 1 Round
1-12 = 1 Round
🔌 Starting Winding
Total Coil – 2
SWG – 33
Turn – 240
Coil Size – 30 inch
SWG – 33
Turn – 240
Coil Size – 30 inch
Coil Pitch – 1-8 = 1 Round
1-10 = 1 Round
1-12 = 1 Round
🔄 Connection समझें
- Running + Starting → Series connection
- Capacitor → Starting winding के साथ
- Supply → दोनों ends पर
⚠️ Important Tips
✔️ Copper wire use करें (better performance)
✔️ Coil pitch बिल्कुल same रखें
✔️ Turns mismatch नहीं होना चाहिए
✔️ Insulation paper जरूर लगाएं
💡 Practical Experience
- Speed कम → capacitor weak
- Heating → turns गलत
- आवाज → balancing issue
📌 Final Note
यह 2 blade Farata fan (2800 RPM, 60mm ID, Copper winding) का data high speed के लिए perfect है।
अगर सही तरीके से winding करेंगे तो fan बहुत smooth और powerful चलेगा।
